Geberit type 383 fill valve for exposed cisterns
My list (0)
Technical data
Flow pressure 10–1000 kPa |
Appliance sound pressure level at 300 kPa / 3 bar 7 dB(A) |
Appliance sound pressure level at 500 kPa / 5 bar 13 dB(A) |
Storage temperature ≤ 40 °C |
Water temperature max. 25 °C |
Durchfluss bei 50 kPa / 0.5 bar 0.06 l/s |
Durchfluss bei 300 kPa / 3 bar 0.16 l/s |
Minimum flow pressure 10 kPa |
Calculated flow rate 0.09 l/s |
Application purposes
Click on an application purpose to search more products
Characteristics
Click on a characteristic to search more products
Scope of delivery
Filter for nipple / reinforced braided hose types 350 and 380 filling valves
Cone screw fitting
Documents
Your input does not return any results
Spare parts
Fill valves Type 383, lateral water supply connection unit
Fill valves Type 383, lateral water supply connection unit
2024 -
| # | Art. no. | Description | Remarks |
|---|---|---|---|
| 2 | 245.988.00.1 | Geberit operating part set for type 383 fill valve | |
| 4 | 240.069.00.1 | Geberit reinforced braided hose | |
| 8 | 240.922.00.1 | Geberit set of seals for reinforced braided hose | |
