With turn handle actuation

Geberit bathtub drain with turn handle, d52, length 76 cm, PP

Thumbnail image

Thumbnail image

Thumbnail image

Thumbnail image

Main gallery image

Main gallery image

Main gallery image

Main gallery image

My list (0)

Articles

Click on the icon with the 3 dots to have more options for each item.

Technical data

Depth of water seal

50 mm

Application purposes

Click on an application purpose to search more products

For bathtubs made of steel, plastic or cast iron For bathtubs with a wall thickness of up to 8 mm For standard-size bathtubs For barrier-free bathtubs For bathtubs with a height of up to 762 mm

For bathtubs with drain and overflow For bathtubs with centre outlet For bathtubs with valve hole ø 52 mm For bathtubs with external trap

Characteristics

Click on a characteristic to search more products

Turn handle actuation With overflow Overflow and outlet made of PP With push-on seal Fulfils standard requirements in accordance with ASME A112.18.2 / CSA B125.2

Fulfils standard requirements in accordance with ASTM F409 Fulfils standard requirements in accordance with NSF/ANSI 14 Fulfils standard requirements in accordance with cUPC Fulfils standard requirements in accordance with NPCC Fulfils standard requirements in accordance with ICC

Scope of delivery

PVC T-piece, 1 1/2"
Overflow assembly
Waste outlet
Cable actuator
Overflow pipe
Outlet pipe
Installation tool
Fastening material

Documents

Your input does not return any results

Spare parts

Bathtub drains with turn handle actuation, d52, PP

Bathtub drains with turn handle actuation, d52, PP

Bathtub drains with turn handle actuation, d52, PP

2001 -

#	Art. no.	Description
1	242.767.00.1	Geberit Befestigungsmaterial für Badewannenablauf mit Drehbetätigung, d52, für Einbaubadewanne 13 mm, US

Open detail page

1 Article
